Type 3
The footed snap seal delivers relatively large travel for its width so it can close large gaps. The dovetail designed base may also be retained mechanically. These profiles are best suited for expansion axially or radially outward. They are not recommended for inward expansion.
Extruded
| Style | W | mm | H | mm | Y Gap | mm | |
| PRS980 | SF | 0.630 | 16.002 | 0.531 | 13.487 | 0.094 | 2.388 |
Molded, Fabric Reinforced
| Style | W | mm | H | mm | Y Gap | mm | |
| PRS599 | B | 0.625 | 15.875 | 0.500 | 12.700 | 0.375 | 9.525 |
| PRS591 | B | 0.687 | 17.450 | 0.500 | 12.700 | 0.438 | 11.125 |
| PRS598 | S | 0.687 | 17.450 | 0.500 | 12.700 | 0.250 | 6.350 |
| PRS709 | SF | 1.000 | 25.400 | 0.625 | 15.875 | 0.312 | 7.925 |
| PRS597 | S | 1.000 | 25.400 | 0.600 | 15.240 | 0.375 | 9.525 |
| PRS581 | B | 1.000 | 25.400 | 0.625 | 15.875 | 0.500 | 12.700 |
| PRS594 | B | 2.000 | 50.800 | 1.218 | 30.937 | 1.219 | 30.963 |
| PRS708 | S | 2.000 | 50.800 | 1.218 | 30.937 | 0.813 | 20.650 |
